RX-DD
Digital Durometer |
Available Scales: A, AO, B, C, D, DO, E, M, O, OO, OOO (Asker, ISO, DIN & JIS Scales also available, inquire)
The new Check-Line RX-DD is a precision Digital Durometer ideal for laboratory use.  It features a large direct drive LCD display, RS232 data ports for computer compatibility, a locking feature to prevent accidental erasure of tolerances, automatic shutoff, low battery warning, and accessories such as MTI and SPC type printers, audio attachments and software.
Type M Durometers require test stand OS-3 per ASTM D2240. |
 High and low buttons for setting tolerance limits | | Solid state circuitry with LCD display | | One year warranty | | Holds Peak reading until reset | | 0.1 Unit Resolution |
| | Supplied in custom fit carrying case | | Includes NIST-Traceable Calibration Certificate | | Conforms to ASTM D-2240 | | Optional Removable Stainless Steel Barrel for Medical and Food Applications | Minimum Sample Thickness
-Type A = 6 mm (1/4")
-Type M = 1.25 mm (0.050") |
|
|
RX-DD-MS
Digital Multi-Scale Durometer |  |
Digital Multi-Scale Durometer allows user to measure in a variety of scales with one guage. | | Click image for more info | | ___________________________________________ |
|
SWC-1
RX Lab Durometer Software |  |
Provides a running log of all measurements along with a chart of the data as well as statistical information Includes RS-232 Cable | | Click image for more info | | ___________________________________________ |
|
Durometer Test Block Kits
Test Function Of Durometers |  |
Enables user to perform a quick check for proper durometer operation | | Click image for more info | | ___________________________________________ |
|
RX-BF
"Big Foot" Durometer Foot Adapter |  |
The Big Foot increases the diameter of the foot from 1/2" to 1 3/8" diameter | | Click image for more info | | ___________________________________________ |
|
RX-CLW
Constant Load Weight for Types A, B, O, OO & OOO |  |
The Constant Load Weight for gauges with an 822g springload (types A, B, O) slides onto the lower barrel of the gauge, gives it a wider foot, and raises the mass of the gauge to the suggested 1kg | | Click image for more info
|
| | | |
The RX-DD is supplied as a complete kit including the durometer, AC adapter & instruction manual in a foam-fitted metal carrying case. |
 |
| Resolution |
0.1 Units |
| Dimensions |
2.25" x 6.125" |
| Weight |
7.15 oz. |
| Power Supply |
(2) 3V CR-2450 Batteries
AC Adapter Optional |
| Warranty |
1 year |
|
|
Features
