ZF2
Tension Meter for Fibers, Yarns and Fine Wires |
Precision movement and light-weight, hard plastic housing makes the Type Z Series ideal for accurately checking the operating or static tensions of a wide variety of process material including delicate yarns, fibers, filaments, wires, etc. |
 A trigger-operated, roller-shifting mechanism and exclusive snare-guide automatically guide the moving filament into the roller V-grooves eliminating breaks and snags. | | Front filament loading permits the operator to observe the filament, rollers and dial at all times. | | NIST-Traceable calibration available |
| | ZF2 roller guides are rated for speeds up to 900 m/min or, optionally, up to 2000 m/min. | | Each instrument is individually calibrated with each scale hand marked to provide the highest reading accuracy | | Supplied in an attractive foam-fitted carrying case. |
|
ZF2 Tension Meter
 |
ZF2 Models
Miniaturized rollers make these models ideal for delicate fibers, low tension or when
access space is limited.
|
 |
ZD2 Models
Recommended for all other applications where miniaturized rollers are not needed.
|
|
| Model |
Range |
| ZF2-5 |
1-5 g |
| ZF2-10 |
1-10 g |
| ZF2-12 |
1-12 g |
| ZF2-20 |
2-20 g |
| ZF2-30 |
3-30 g |
| ZF2-50 |
5-50 g |
| ZF2-100 |
10-100 g | | |
| Accuracy |
±1% of Full Scale or
±1 graduation mark on scale |
| Outer roller distance:c: |
22 mm (0.87") |
| Diameter of Dial |
54 mm (2.13") |
| Dimensions |
150 x 120 x 30 mm
(5.9" x 4.7" x 1.2") |
| Weight |
210 g (7.5 oz.) |
| Roller Material |
Standard - Hard-coated aluminum
Optional - Phenolic Plastic |
| Maximum Linear Speed |
Standard - 900 meters/min
Optional - 2000 meters/min (K) |
| Other Options |
Calibration for horizontal material path (rollers pointing down)(D)
Memory pointer |
|
Roller Guide
