| Measuring principle: |
Magnetic induction method (F-version); Eddy current method (N-version) |
| Measuring range: |
3000PRO & 3000PRO-FN90:
0 - 60.00 mils / 0 - 1500 µm
3000PRO-F10:
0 - 400 mils / 0 - 10,000 µm |
| Tolerance: |
± (0.7 µm/0.04 mils + 1% of reading) |
| Resolution: |
Refer to RESOLUTION TABLE, above |
| Display: |
4-digit display (digit height 10 mm/0.4”) and 32 alphanumerical characters; switchable backlight |
| Minimum measurement area: |
5 mm x 5mm/0.2” x 0.2” |
| Minimum curvature radius: |
convex 2mm/0.08”; concave 5mm/0.2” |
| Minimum substrate thickness: |
0.2mm/8 mils (for F-versions); 50 µm/2 mils (for N-versions) |
| Calibration methods: |
- Factory calibration: no calibration required for standard applications
- Zeroing (1-point calibration): measurements on small geometries
- Zeroing and foil calibration (2-point calibration): increased measuring accuracy
- Two-foil calibration: especially for rough, sand-blasted surfaces
- CTC: calibration on coated object if zeroing is not possible
- Zero offset: addition/subtraction of a constant value to/from the reading |
| Limit values: |
Selectable; optical and acoustic signal if limit value is exceeded |
| Scan mode: |
For continuous measurements; for the quick recognition of coating thickness variations;
with permanent display of minimum and maximum reading |
| Statistics: |
Single-value statistics: n, avarage x, s, kvar, min, max, cp, cpk from max. 10,000 readings
Block-value statistics: n, avarage x , avarage s, avarage kvar , min, max, cp, cpk; block size 3 to 100 readings |
| Data memory: |
10,000 readings in max. 500 selectable files; alphanumerical file names; stored readings and statistical values individually recallable |
| Interfaces: |
Infrared and serial RS232 interface |
| Language: |
Operator prompting and documentation in German, English, French (optional other languages) |
| Operating temperature: |
0 °C to 50 °C/32 °F to 122 °F (storage temperature - 20 °C to +60 °C/-4 °F to 140 °F) |
| Surface temperature: |
5° F - 140° F / -15° C - 60° C (standard)
5° - 302° F / 15° - 150° C (w/optional footer) |
| Power supply: |
2 x round cell (AA) 1.5 V up to 60 hours of operating time |
| Housing/keypad: |
Protection class IP52 (protection against dust and dripping water) |
| Dimensions: |
Gauge: 140 mm x 62 mm x 30mm/5.6” x 2.5” x 1.2” (HxWxD)
Probe: dia. 14 mm x 83mm/dia. 0.56” x 3.3” |
| Weight: |
approx. 200 g/7 oz (gauge including batteries and probe) |
| Standards: |
DIN EN ISO, ASTM, BS |
| Warranty |
1 Year |
| Calibration Certificate |
Included |
Features
Automatic identification of the substrate
